Lead acid batteries, worldwide, EN60601 medical

These chargers developed for medical applications for worldwide use are suitable for the rapid and subsequent continuous charging of maintenance-free, valve-regulated and open lead batteries.

  • Danger:
    The devices are not protected against polarity reversal. The correct polarity connection to the battery must be observed and ensured using polarity-protected connections. Incorrect polarity will destroy the device.



  • Input voltage: 100-240 VAC ±10% / 50-60 Hz
  • Charging characteristic: IU
  • Charging current display: LED
  • Loading time: unlimited possible
  • Parallel operation possible directly with load, note max. consumer current.
  • Trickle charge: automatically after full charge
  • Output cable: 2 m with reversible universal coupling
  • Approval according to EN60601 (medical application)



  • Not included in the delivery:
    For secondary plug attachments, see the power supply accessories chapter
    Only charge Pb batteries.
    Do not open. Repairs only permitted by the manufacturer.

There are 8 of 8 products shown.

2615-FW7118M/06

  • Description: LSGBW1P6V/0.9AIUmed
  • Weight [g]: 0.105 g
  • Length [mm]: 74 mm
  • Width [mm]: 29 mm
  • Height [mm]: 43 mm
  • Voltage [V]: 6 VDC
  • Manufacturer: FRIWO
2615-FW7118M/06

2661-FW7318M/24-1.0

  • Description: LEGBW6P24V/1Amed
  • Weight [g]: 0.26 g
  • Length [mm]: 105 mm
  • Width [mm]: 68 mm
  • Height [mm]: 39 mm
  • Voltage [V]: 24 VDC 2 Stufen
  • Manufacturer: FRIWO
2661-FW7318M/24-1.0

2775-FW7318M/24-1.5

  • Description: LEGBW6P24V/1.5Amed
  • Weight [g]: 0.26 g
  • Length [mm]: 105 mm
  • Width [mm]: 68 mm
  • Height [mm]: 39 mm
  • Voltage [V]: 24 VDC 2 Stufen
  • Manufacturer: FRIWO
2775-FW7318M/24-1.5

2750-FW7118M/12

  • Description: LSGBW1P12V/0.5AIUme
  • Weight [g]: 0.105 g
  • Length [mm]: 74 mm
  • Width [mm]: 29 mm
  • Height [mm]: 43 mm
  • Voltage [V]: 12 VDC
  • Manufacturer: FRIWO
2750-FW7118M/12

2592-FW7318M/12

  • Description: LEGBW6P12V/2Amed
  • Weight [g]: 0.26 g
  • Length [mm]: 105 mm
  • Width [mm]: 68 mm
  • Height [mm]: 39 mm
  • Voltage [V]: 12 VDC 2 Stufen
  • Manufacturer: FRIWO
2592-FW7318M/12

2576-FW7218M/12

  • Description: LEGBW6P12V/1Amed
  • Weight [g]: 0.225 g
  • Length [mm]: 87.5 mm
  • Width [mm]: 51.5 mm
  • Height [mm]: 34 mm
  • Voltage [V]: 12 VDC 2 Stufen
  • Manufacturer: FRIWO
2576-FW7218M/12

2660-FW7218M/24

  • Description: LEGBW6P24V/0.5Amed
  • Weight [g]: 0.225 g
  • Length [mm]: 87.5 mm
  • Width [mm]: 51.5 mm
  • Height [mm]: 34 mm
  • Voltage [V]: 24 VDC 2 Stufen
  • Manufacturer: FRIWO
2660-FW7218M/24

2577-FW7218M/6

  • Description: LEGBW6P6V/1.6Amed
  • Weight [g]: 0.225 g
  • Length [mm]: 87.5 mm
  • Width [mm]: 51.5 mm
  • Height [mm]: 34 mm
  • Voltage [V]: 6 VDC 2 Stufen
  • Manufacturer: FRIWO
2577-FW7218M/6
Description

Voltage [V]

Current [A]
