RF-Switch

Nisshinbo Micro Devices provides RF switches that cover various communication applications such as 5G, Wi-Fi 6/6E and so on. The advantages of high performance switches are low insertion loss, high isolation and high linearity even if high frequency band by our unique GaAs process. Furthermore, integrated ESD protection elements achieve excellent ESD robustness.They also offer automotive grade products. In addition, Nisshinbo develop RF devices by SOI process.

There are 10 of 44 products shown.

NJG1816K75

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 30
  • Power Level: High Power
  • Insertion Loss [dB]: 0,45@920MHz 0,50@2,4 to 2,5GHz
  • Isolation [dB]: 30@920MHz 22@2,4 to 2,5GHz
  • Manufacturer: Nisshinbo
NJG1816K75

NJG1806K75

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 31
  • Power Level: High Power
  • Insertion Loss [dB]: 0,35@0,7GHz 0,35@1,9GHz 0,35@2,4 to 2,5GHz 0,4@4,9 to 5,9GHz
  • Isolation [dB]: 30@0,7GHz 25@1,9GHz 25@2,4 to 2,5GHz 25@4,9 to 5,9GHz
  • Manufacturer: Nisshinbo
NJG1806K75

NJG1801K75

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 31
  • Power Level: High Power
  • Insertion Loss [dB]: 0,35@2,4 to 2,5GHz 0,45@4,9 to 5,9GHz 0,60@8,5GHz
  • Isolation [dB]: 28@2,4 to 2,5GHz 30@4,9 to 5,9GHz 20@8,5GHz
  • Manufacturer: Nisshinbo
NJG1801K75

NJG1815K75

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 31
  • Power Level: High Power
  • Insertion Loss [dB]: 0,45@2,4 to 2,5GHz 0,4@4,9 to 6GHz
  • Isolation [dB]: 25@2,4 to 2,5GHz 25@4,9 to 6GHz
  • Manufacturer: Nisshinbo
NJG1815K75

NJG1815AK75-A Automotive

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 31
  • Power Level: High Power
  • Insertion Loss [dB]: 0,45@2,4 to 2,5GHz 0,45@3,4 to 3,8GHz 0,4@4,9 to 6GHz
  • Isolation [dB]: 25@2,4 to 2,5GHz 25@3,4 to 3,8GHz 25@4,9 to 6GHz
  • Manufacturer: Nisshinbo
NJG1815AK75-A Automotive

NJG1818K75

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch
  • P-1dB [dBm]: 31
  • Power Level: High Power
  • Insertion Loss [dB]: 0,50 @2,4 to 2,5 GHz 0,50 @4,9 to 5,9 GHz 0,55 @5,9 to 7,125 GHz
  • Isolation [dB]: 25dB @2,4 to 2,5 GHz 25dB @4,9 to 5,9 GHz 25dB @5,9 to 7,125 GHz
  • Manufacturer: Nisshinbo
NJG1818K75

NJG1697EM1

  • Package (RF-Switch): DFN6
  • Features: SPDT Switch, High Isolation
  • P-1dB [dBm]: 21
  • Power Level: Low Power
  • Insertion Loss [dB]: 0,45@1GHz 0,50@2GHz 0,55@2,7GHz
  • Isolation [dB]: 50@1GHz 48@2GHz 43@2,7GHz
  • Manufacturer: Nisshinbo
NJG1697EM1

NJG1660HA8

  • Package (RF-Switch): USB6
  • Features: SPDT Switch
  • P-1dB [dBm]: 32
  • Power Level: High Power
  • Insertion Loss [dB]: 0,35@2,5GHz 0,45@3,5GHz 0,50@6,0GHz
  • Isolation [dB]: 33@2,5GHz 30@3,5GHz 21@6,0GHz
  • Manufacturer: Nisshinbo
NJG1660HA8

NJG1808K94

  • Package (RF-Switch): QFN9
  • Features: SP3T Switch
  • P-1dB [dBm]: 24
  • Power Level: Low Power
  • Insertion Loss [dB]: 0,35@1,0GHz 0,4@2,0GHz 0,4@2,7GHz
  • Isolation [dB]: 29@1,0GHz 26@2,0GHz 24@2,7GHz
  • Manufacturer: Nisshinbo
NJG1808K94

NJG1615HA8

  • Package (RF-Switch): USB6
  • Features: SPDT Switch
  • P-1dB [dBm]: 27
  • Power Level: High Power
  • Insertion Loss [dB]: 0,55@5,85GHz
  • Isolation [dB]: 25@2,5GHz
  • Manufacturer: Nisshinbo
NJG1615HA8
Package

P-1dB [dBm]

Type
