Nisshinbo

Nisshinbo Micro Devices Inc. Your Partner for Analog Solution

NISSHINBO was founded at the beginning of 2022 through the merger of NJR and RICOH and has over 60 years of experience in alalog semiconductor. The company is focused on development and production of high quality OPAmps, Power Management IC, audio and RF device. Using bipolar, CMOS and BCD technology Nisshinbo provides a wide range of products for consumer as well for industrial and automotive application.
Using own factories and technology they can commit for long term supply and also customer made device with high quality standards.


Productportfolio

Operational Amplifier, Comparator, Switching Regulator, LDO, AD- and DA Converterr, Supervision IC, RF-switch, LNA, Radar-Modue, Photodiode and ASIC

Possible Application

  • Healtcare
  • Wireless Communication
  • Automotive
  • Consumer
  • Industrial

Certifications and quality management

  • ISO 9001:2015
  • ISO 14001:2015
  • IATF 16949:2016

There are 10 of 811 products shown.

NJG1608KB2

  • Package (RF-Switch): FLP6
  • Features: SPDT Switch
  • P-1dB [dBm]: 27
  • Insertion Loss [dB]: 0,3@2,0GHz 0,5@2,5GHz 0,6@5,85GHz
  • Isolation [dB]: 29@2,0GHz 30@2,5GHz 18@2,5GHz
  • Manufacturer: Nisshinbo
NJG1608KB2

NJG1686MHH

  • Package (RF-Switch): QFN26
  • Features: SP10T Switch
  • P-1dB [dBm]: -
  • Insertion Loss [dB]: 0,65@452 to 960MHz 0,30@452 to 960MHz 0,75@1710 to 2170MHz 0,45@1710 to 2170MHz 1,10@2300 to 2690MHz 0,45@2300 to 2690MHz 1,05@GSM850/900 1,20@GSM1800/1900
  • Isolation [dB]: 38@GSM850/900 34@GSM1800/1900 25@452 to 2690MHz 36@1805 to 1990MHz 33@452 to 2690MHz
  • Manufacturer: Nisshinbo
NJG1686MHH

NJG1617K11

  • Package (RF-Switch): QFN12
  • Features: DPDT Switch
  • P-1dB [dBm]: 31
  • Insertion Loss [dB]: 0,75@6GHz
  • Isolation [dB]: 25@6GHz
  • Manufacturer: Nisshinbo
NJG1617K11

NT1821GVAE1S

  • Package (RF-Switch): DFN6
  • Features: 1.0 to 7.125 GHz High Isolation SPDT Switch
  • P-1dB [dBm]: 31
  • Insertion Loss [dB]: Typ. 0.60 dB @ 2.4 to 2.5 GHz 0.50 dB @ 4.9 to 5.9 GHz 0.58 dB @ 5.9 to 7.125 GHz
  • Isolation [dB]: Typ. 40 dB @ 2.4 to 2.5 GHz 38 dB @ 4.9 to 5.9 GHz 42 dB @ 5.9 to 7.125 GHz
  • Manufacturer: Nisshinbo
NT1821GVAE1S

NT1822GVAE1S

  • Package (RF-Switch): DFN6
  • Features: 1.0 to 7.125 GHz High Isolation SPDT Switch
  • P-1dB [dBm]: 31
  • Insertion Loss [dB]: 0.60 dB@2.4 to 2.5 GHz
  • Isolation [dB]: Typ. 40 dB@2.4 to 2.5 GHz
  • Manufacturer: Nisshinbo
NT1822GVAE1S

NT1819NAAE2S

  • Features: Absorptive High Isolation SPDT Switch
  • P-1dB [dBm]: 31
  • Insertion Loss [dB]: Typ. 0.70/0.80/0.85/0.90/1.2 dB @0.7/3.85/4.7/6.0/7.125 GHz
  • Isolation [dB]: Typ. 70/62/60/55/51 dB @ 0.7/3.85/4.7/6.0/7.125 GHz
  • Manufacturer: Nisshinbo
NT1819NAAE2S

NJR4234BWF2C1 Distance Measurement Module

  • min. Detection range person [m]: 20 m
  • Movement: yes
  • Direction: no
  • Speed: no
  • Distance: yes
  • Angle: no
  • Opening angle vertical [°]: 42 °
  • Opening angle horizontal [°]: 28 °
  • Manufacturer: Nisshinbo
NJR4234BWF2C1 Distance Measurement Module

NJR4266F2A1 Motion Detector

  • min. Detection range person [m]: 7 m
  • Movement: yes
  • Direction: no
  • Speed: no
  • Distance: no
  • Angle: no
  • Opening angle vertical [°]: 80 °
  • Opening angle horizontal [°]: 80 °
  • Manufacturer: Nisshinbo
NJR4266F2A1 Motion Detector

NJR4266F2A2 Motion Detector

  • min. Detection range person [m]: 7 m
  • Movement: yes
  • Direction: no
  • Speed: no
  • Distance: no
  • Angle: no
  • Opening angle vertical [°]: 80 °
  • Opening angle horizontal [°]: 80 °
  • Manufacturer: Nisshinbo
NJR4266F2A2 Motion Detector

NJR4266F2B1 Motion Detector

  • min. Detection range person [m]: 10 m
  • Movement: yes
  • Direction: no
  • Speed: no
  • Distance: no
  • Angle: no
  • Opening angle vertical [°]: 80 °
  • Opening angle horizontal [°]: 50 °
  • Manufacturer: Nisshinbo
NJR4266F2B1 Motion Detector
