Lithium manganese dioxide primary cells

LiMn batteries are used in a wide range of applications, such as IoT and small applications. Thanks to their flat design, these batteries fit very well in devices with a low overall height or where the application is to be built and designed as small as poβible. Our team can support you with a wide range of products and will be happy to provide further information.

There are 10 of 65 products shown.

CR2 (Jauch)

  • Voltage [V]: 3 V
  • Capacity [mAh]: 900 mAh
  • Max. Discharge current[mA]: 850 mA
  • Max. pulse current[mA]: 1,500 mA
  • temperature [°C]: -40 ~ +70
  • Manufacturer: Jauch
CR2 (Jauch)

CR2016

  • Voltage [V]: 3 V
  • Capacity [mAh]: 80 mAh
  • Max. Discharge current[mA]: 3 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -20 ~ +70
  • Manufacturer: EVE
CR2016

CR2

  • Voltage [V]: 3 V
  • Capacity [mAh]: 850 mAh
  • Max. Discharge current[mA]: 1,000 mA
  • Max. pulse current[mA]: 2,000 mA
  • temperature [°C]: -40 ~ +85
  • Manufacturer: EVE
CR2

CR 2477 V3 (Jauch)

  • Voltage [V]: 3 V
  • Capacity [mAh]: 1,000 mAh
  • Max. Discharge current[mA]: 2 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -30 ~ +70
  • Manufacturer: Jauch
CR 2477 V3 (Jauch)

CR 2450 V3 (Jauch)

  • Voltage [V]: 3 V
  • Capacity [mAh]: 610 mAh
  • Max. Discharge current[mA]: 4 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -30 ~ +70
  • Manufacturer: Jauch
CR 2450 V3 (Jauch)

CR 2032 H3B (Jauch)

  • Voltage [V]: 3 V
  • Capacity [mAh]: 240 mAh
  • Max. Discharge current[mA]: 3 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -30 ~ +70
  • Manufacturer: Jauch
CR 2032 H3B (Jauch)

CR 2032 V3 (Jauch)

  • Voltage [V]: 3 V
  • Capacity [mAh]: 240 mAh
  • Max. Discharge current[mA]: 3 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -30 ~ +70
  • Manufacturer: Jauch
CR 2032 V3 (Jauch)

CF102836

  • Voltage [V]: 3 V
  • Capacity [mAh]: 200 mAh
  • Max. Discharge current[mA]: 0.5 mA
  • Max. pulse current[mA]: 15 mA
  • temperature [°C]: -10 ~ +60
  • Manufacturer: EVE
CF102836

CF042039

  • Voltage [V]: 3 V
  • Capacity [mAh]: 25 mAh
  • Max. Discharge current[mA]: 0.25 mA
  • Max. pulse current[mA]: 5 mA
  • temperature [°C]: -10 ~ +60
  • Manufacturer: EVE
CF042039

CP104851

  • Voltage [V]: 3 V
  • Capacity [mAh]: 380 mAh
  • Max. Discharge current[mA]: 30 mA
  • temperature [°C]: -40 ~ +60
  • Manufacturer: Fanso
CP104851
Voltage [V]

Capacity [mAh]

Max. discharge current [mA]

Max. pulse current [mA]

temperature [C°]
